Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit

Large Image : Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit

Product Details:

Place of Origin:	Heibei province China
Brand Name:	JSBIT
Certification:	API and ISO standard
Model Number:	7 7/8inch 200mm

Payment & Shipping Terms:

Minimum Order Quantity:	1 pcs
Price:	bargain
Packaging Details:	Fumigation-free export wooden box
Delivery Time:	1 days
Payment Terms:	Western Union, T/T
Supply Ability:	500PCS /month

Contact Now

Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit

Description

Product Name:	Tricone Drill Bit，Tic Bit，oil Drill Bit	Application:	Coal Mining, Quarry Drilling, Drilling
Product Process:	Forging And Heat Treatment	Bearing:	Open Bearing Type,air Bearing Type,air Cool Bearing Type
Material:	20GrNiMo And Tungsten Carbide	Warranty:	More Than 80 Hours
Standard:	API And ISO	Usage:	HDD Drilling, Oil Drilling, Crossing Strata, Water Well Drilling.
Machinable Size:	7 7/8inch 200mm	Country Of Origin:	Hebei，china
Highlight:	200mm Tricone Drill Bit , Open Bearing Tricone Drill Bit , 7/8inch Tricone Drill Bit

Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit

JSBIT tricone bits factory offers all kinds of tricone drill bits. Tricone bits are available in new and used tricone bits , steel tooth and tungsten carbide insert, in sizes from 37/8" to 36", for use in all formations, with any bearing: seal type / air type , tricone bits apply to oil gas geothermy mining water HDD and foundation industry.

Main features:

1. Cutting Structure of this type sealed and non-sealed tci tricone bits

Tungsten carbide insert tricone bit : tungsten carbide alloy steel

Steel tooth tricone bit : Enhancing the wear-resistance of cutting tooth by welding new type of wear resistant material on the tooth surface of steel tooth bit. Reinforcing the comprehensive mechanical properties of cutting tooth by using high quality tungsten carbide inserts of new formula and new techniques of insert bit.

2. Gauge Structure of this type tci tricone rock bits:

Gauge Structure

The multiple heel position with gauge trimmer on the heel, tungsten carbide and hardfacing on the shirttail, strengthened spear point will enhance the gauge protection.

IADC	Recommended parameters		Applicable strata
IADC	WOB KN/mm	Rotating speed r/min	Applicable strata
116,117	0.35-0.8	150-80	Extremely soft formations with high compressive strength and drillability, such as clay, mudstone, chalk
126,127	0.35-0.9	150-70	Soft formations with high compressive strength and drillability, such as mudstone, gypsum, salt rock, soft shale, soft limestone
136,137	0.35-1.0	120-60	Soft to medium-soft formations with high compressive strength and high drillability, such as medium-soft shale, anhydrite, medium-soft limestone, medium-soft sandstone and soft formations with hard interlayers
216,217	0.4-1.0	100-60	Soft to medium formations with compressive strength, such as soft shale, medium soft limestone, medium soft sandstone and soft formations with hard interlayers
246,247	0.4-1.0	80-50	Medium-hard formations with high compressive strength, such as hard shale, limestone, sandstone, dolomite
417,437,447	0.35-0.9	150-70	Very soft formations with high compressive strength and drillability, such as clay, mudstone, chalk, gypsum, salt rock, soft shale, soft limestone
517,527	0.35-1.0	140-60	Soft formations with high compressive strength, such as mudstone, gypsum, salt rock, soft shale, soft limestone
537,547	0.45-1.0	120-50	Soft to medium formations with compressive strength, such as medium-soft shale, medium-soft limestone, medium-soft sandstone and medium formations with effective hard abrasive interlayers
617,627	0.45-1.1	90-50	Medium-hard formations with high compressive strength, such as hard shale, limestone, sandstone, dolomite
637	0.5-1.2	80-40	Hard formations with high compressive strength, such as sandstone, limestone, dolomite and anhydrite, marble

Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit 0

Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit 3

Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit 4

Factory 7 7/8inch 200mm IADC642 Open Bearing Type Tricone Drill Bit 7
